Conveyor Magnetic Separator
l Product introduction
Self-discharging electro conveyor magnetic belt separator RCDD series is designed for long term operating shift provided with self-discharge function and semi-sphere shaped magnetic field. Installed with continuous operating trump iron discharging conveyor which helps to throw the attracted magnetic material into the iron collection tray. Conveyor magnetic separator is suitable for removing the magnetic iron particles from the thicker bed of the material and material under bigger granularity such as ores, coals, hard cokes, limestone and etc.
l Product features
1. Used to remove iron particles from material
2. Self-discharging tramp iron/metal
3. Uninterrupted duty
4. Japanese production standard
5. Half sphere shaped magnetic field
6. Moving conveyor for unloading
l Main technical data
Model | Installation height (mm) | Belt width (mm) | Voltage (V) | Mass of machine(kg) |
RCDD-4 | 160 | 400 | 110 | 1074 |
RCDD-5 | 170 | 500 | 110 | 1074 |
RCDD-6A | 220 | 600 | 110 | 1330 |
RCDD-6 | 250 | 650 | 110 | 1470 |
RCDD-8 | 250 | 800 | 110 | 2000 |
RCDD-10 | 310 | 1000 | 220 | 2700 |
RCDD-12 | 350 | 1200 | 220 | 4200 |
RCDD-14 | 410 | 1400 | 220 | 6020 |
RCDD-16 | 450 | 1600 | 220 | 8260 |
RCDD-18 | 490 | 1800 | 220 | 7900 |
RCDD-20 | 550 | 200 | 220 | 15500 |
RCDD-22 | 550 | 2200 | 220 | 17500 |
Warmly welcome you come to visist our factory.
Our factory located at Ganzhou city, Jiangxi province, China.
Take flight from your country to Guangzhou airport in China, and then take flight from Guangzhou-- to Gan zhou airport, then we will send the car to pick up you from Ganzhou airport.
