SHIJIAZHUANG SHUANGLU MACHINERYCO.,LTD.
Welding electrodes/rods making machine/production line/electrodes conveyor machines
1.Welding Electrodes Making Machine
2.Optional Output Capacity
3.Factory Supply
4.ISO9001:2008
SJB-16 Electrode Conveyor Machine
SJB-16 Electrode Conveyor Machine, as the special production equipment for welding electrodes, can complete the transferring procedure from hydraulic powder coating machine to head end grinding machine.
Specifications and Parameters
No. | Name | Specifications and Parameters |
1 | Conveying Diameter | Φ2.5-Φ5.8mm |
2 | Conveying Speed | 225-467M/min |
3 | Rotation Angle | 180° |
4 | Elevation Regulation | 0°-12° |
5 | Power | 1.1kw |
6 | Dimensions | 1600*450*1000mm |
7 | Weight | 0.35T |
product photo
Model | Belt width<mm | Suspension heighth mm | Magnetic field intensity >mT | Material depth <mm | Driving power <kw | Belt speed <m/s | Weigh kg | Appearance size mm | |||
A | B | C | D | ||||||||
RCDB-3 | 300 | 75 | 50 | 50 | 0.4 | 4.5 | 185 | 210 | 250 | 400 | 280 |
RCDB-4 | 400 | 100 | 50 | 70 | 0.6 | 300 | 240 | 280 | 500 | 400 | |
RCDB-5 | 500 | 150 | 60 | 90 | 1 | 430 | 280 | 325 | 610 | 450 | |
RCDB-6.5 | 650 | 200 | 70 | 150 | 2 | 680 | 280 | 325 | 816 | 500 | |
RCDB-8 | 800 | 250 | 70 | 200 | 3.6 | 950 | 310 | 355 | 960 | 640 | |
RCDB-10 | 1000 | 300 | 70 | 250 | 5 | 1520 | 310 | 360 | 1200 | 780 | |
RCDB- 12 | 1200 | 350 | 70 | 300 | 6.8 | 2250 | 310 | 365 | 1400 | 920 | |
RCDB-14 | 1400 | 400 | 70 | 350 | 9 | 2950 | 405 | 485 | 1650 | 1000 | |
RCDB-16 | 1600 | 450 | 70 | 400 | 13 | 4800 | 460 | 540 | 1900 | 1650 | |
RCDB-18 | 1800 | 500 | 70 | 450 | 18 | 6900 | 530 | 610 | 2150 | 1800 |
